TS5A23157-Q1 汽车类双路 15Ω SPDT 模拟开关

描述

TS5A23157是一款双通道单刀双掷（SPDT）模拟开关，设计工作电压范围为1.65 V至5.5 V.此设备可以处理数字和模拟信号。该器件可在任一方向上传输高达5.5 V（峰值）的信号。

有关最新的封装和订购信息，请参阅本文档末尾的封装选项附录，或参见TI网站在www.ti.com。


Configuration
Number of Channels (#)
Power Supply Type
Vss (Min) (V)
Vss (Max) (V)
Vdd (Min) (V)
Vdd (Max) (V)
Ron (Typ) (Ohms)
Bandwidth (MHz)
Rating
Operating Temperature Range (C)
Package Size: mm2:W x L (PKG)
Package Group
Supply Range (Max)
Ron (Max) (Ohms)
Input/Output Continuous Current (Max) (mA)
Supply Current (Typ) (uA)
Supply Current (Max) (uA)
Features
OFF-state leakage current (Max) (µA)
ON-state leakage current (Max) (µA)
Input/Output ON-state Capacitance (Typ) (pF)
Input/Output OFF-state Capacitance (Typ) (pF)
ESD Charged Device Model (kV)
ESD HBM (kV)
VIL (Max) (V)
VIH (Min) (V)

TS5A23157-Q1	TS3A5018	TS5A23157
2:1 SPDT	2:1 SPDT	2:1 SPDT
2	4	2
Single	Single	Single
N/A	N/A	N/A
N/A	N/A	N/A
1.65	1.65	1.65
5.5	3.6	5.5
15	5.5	10
220	300	220
Automotive	Catalog	Catalog
-40 to 105 -40 to 125	-40 to 85	-40 to 85
10VSSOP: 15 mm2: 4.9 x 3(VSSOP)	16SOIC: 59 mm2: 6 x 9.9(SOIC) 16SSOP: 29 mm2: 6 x 4.9(SSOP) 16TSSOP: 32 mm2: 6.4 x 5(TSSOP) 16TVSOP: 23 mm2: 6.4 x 3.6(TVSOP) 16UQFN: 5 mm2: 1.8 x 2.6(UQFN) 16VQFN: 14 mm2: 3.5 x 4(VQFN)	10UQFN: 3 mm2: 2 x 1.5(UQFN) 10VSSOP: 15 mm2: 4.9 x 3(VSSOP)
VSSOP	SOIC SSOP TSSOP TVSOP UQFN VQFN	UQFN VSSOP
5.5	3.6	5.5
180	22	140
50	64	50
0.01	0.7
0.75	2	10
Break-before-make		Break-before-make
1	10	1
1	2	1
17.5	16	17.5
5.5	3	5.5
0.75	1	1
2	2	2
Vdd*.3	0.8	Vdd*.3
Vdd*.7	1	Vdd*.7
